Rotary Drilling Rigs for Foundations
Hydraulic rotary rigs on crawler for bored piles, CFA piles and casing work. We supply the IMT AF series — from the compact AF 125 to the AF 300 for piles up to 3 m in diameter — new or used, with Kelly bars, tools and after-sales support.
Main specifications
| Model | Max. torque (kNm) | Main winch pull (kN) | Max. drilling depth (m) | Max. pile diameter (mm) | Operating weight (t) |
|---|---|---|---|---|---|
| AF 125 | 117 | 120 | 47 | 1,500 | 33 |
| AF 130 | 117 | 120 | 47 | 1,500 | 33 |
| AF 180 D | 205 | 180 | — | 1,800 | 54 |
| AF 220 | 260 | 240 | 66 | 2,000 | 70 |
| AF 240 | 275 | 240 | — | 2,000 | 80 |
| AF 280 | 310 | 310 | 75 | 2,300 | 91 |
| AF 300 | 350 | 300 | 91 | 3,000 | 110 |
Figures are indicative and as published by the manufacturer. Ask us for the full data sheet.
